EX-CR 0811 Cartridge Filling Machines YOUTUBE VİDEO 900€
Technical Faetures EX-CR 0811

Black filling with right volume adjustmentfrom nozzle
Functional chromium filling and vacuumapparatus

  • Chrome body
  • Black filling from nozzle
  • Special design sensored needle for filling
  • Functional Chrome apparatus Black;Filling &Vacuum
  • Precise tracing with Pressure reader
  • Micro processor control
Technical Faetures
  • Many black cartridge models can be filled from nozzle thanks to special and functional chromium apparatus.Clogged cartridges can be seen thanks to pressure gauge.
  • System can be integrated to 800 series machines.
  • Cartridges that filled with chromium apparatus can be filled perfectly thanks to volume adjustment bar which is first on the world.
  • For clogged cartridges speed reduced and filling repeated thanks to automatic speed controlled pumps while filling with chromium apparatus.
  • Ink in the cartridge can be emptied to waste or clean ink tank.
  • Black cartridges with felt, which are can not be filled with apparatus,are can be filled with special sensitive needle.
  • With keypad counter can be followed or device can be adjusted.
  • Easy to use with colorful buttons and path on the panel.
  • Warning signal when ink finished in the tank.
  • Warning signal for clogged cartridges.
  • Chromium body, follow operation with sound (buzzer), design for no need to extra device, low energy consumption, microcontroller based control.
  • Ink tanks can be enlarged and changed easily.
  • Design for easy to maintenance.
  • Power Supply : 220V 50Hz, (110V or 12V optional)
  • Dimensions : 25x30x39(h)
  • Weight : 9 Kg +/- %6
